FR Nylon twill webbing

"FR nylon webbing" refers to Flame-Retardant (FR) nylon webbing, which is standard nylon material treated with a chemical finish to make it resistant to ignition and self-extinguish when the flame source is removed. Nylon is highly valued for its exceptional strength and abrasion resistance, making it suitable for demanding safety and military applications.

Features

Flame Resistance: FR nylon is engineered to meet specific flammability standards, such as FAR 25.853(a) or NFPA 701/2112, requiring it to resist ignition, have a limited "after-flame," and prevent melting or dripping when exposed to a flame.

High Strength: Nylon naturally possesses very high tensile strength (some variants exceeding 4,000 lbs for a 1-inch width), making it ideal for heavy-duty load-bearing applications.

Durability: It offers superior abrasion resistance compared to other common webbing materials like polyester or polypropylene.

Water Absorption: A key consideration is that standard nylon can absorb water, which may affect its performance in frequently wet outdoor applications unless treated with water-repellent finishes.

Aesthetics: Nylon readily accepts dyes, allowing for a wide range of vibrant colors that enhance the aesthetic appeal of products.washing, which is important for reusable safety gear.

Applications

Aerospace & Aviation: Used in cargo netting, seat belts, and harnesses for aircraft and rotorcraft to meet stringent FAA flammability requirements.

Military & Defense: Applied in military gear, tactical equipment, and parachutes due to its durability and ability to meet Mil-Spec standards.

Industrial Safety: Found in fall protection systems, harnesses, and safety straps for workers in high-risk environments.

Automotive: Used for interior fasteners and seatbelts that must pass automotive flammability standards (e.g., FMVSS 302)

Webbing Customization

● Material: PP, Nylon, Nylon 6.6, Recycled, Polyester, Polyester/Cotton Blends, Dull yarn, Aramid, Kevlar, UHMWPE

● Function: Anti infrared ( 350-3000nm ), Fireproof ( FAR 25, ISO 3795 ), Waterproof ( Fluorine -Free ), Anti-UV ( Color fastness 4-5 grade ), Resin treatment etc.

● Camouflage: customized, available in double sides pattern matching.

● Color: customized, Pantone, RAL, LAB value, fabric, webbing swatch.

● Specification: Width in 5-300 mm, thickness in 0.5-8 mm

● Weave: Flat, plain, tubular, twill, herringbone etc.
